AIMS Power 5000 Watt 24 Volt Power Inverter (PWRINV500024W)

AIMS Power PWRINV500024W 5000 Watt 24 Volt Power Inverter is a powerful and efficient solution for converting 24V DC power into 120V AC power. Designed to support a wide range of devices, including heaters, air conditioners, and kitchen appliances, this inverter is perfect for both everyday use and emergency backup power. Its modified sine wave output ensures stable performance, while built-in features such as a voltmeter and ammeter enhance convenience and safety.

Features:

5000W continuous power with 10,000W surge capacityModified sine wave output with phase correction for stable performanceQuadruple AC outlets (Type 2 – 3 prong) for multiple connectionsBuilt-in voltmeter and ammeter for real-time monitoringBattery low voltage alarm and shutdown for battery protectionHigh input voltage protection to prevent damageAutomatic shutdown at extreme temperatures for safetyInternally fuse-protected system for enhanced reliabilityPre-wired for a remote on/off switchPre-slotted mounting plate for easy installation

Benefits:

Reliable power source for home, RV, and off-grid applicationsHandles high-powered appliances and essential toolsCost-effective alternative to pure sine wave invertersBuilt-in safety features protect connected devices and batteriesLightweight and easy to install with pre-mounting slotsIdeal backup power solution for emergencies and outagesIncludes a 1-year warranty and free tech support

Technical Specifications:

Model Number: PWRINV500024WContinuous output power: 5000 WattsSurge power capability: 10,000 WattsDC input operating voltage: 20 to 34 VoltsOutput voltage: 120 Volts AC ± 10%Output waveform: Modified sine wave with phase correctionOutput frequency: 60 Hz ± 1 HzBattery low voltage alarm: 21.0 ± 0.5 VoltsBattery low voltage shutdown: 20.0 ± 0.5 VoltsNo load current: < 0.4 AmpsFull load efficiency: 90%1/3 load efficiency: 95%Minimum operating temperature: -15°CMaximum operating temperature: 55 ± 5°C (automatic shutdown)AC output socket type: Quadruple Type 2 - 3 prongHigh input voltage protection: 34.5VLow input voltage shutdown: 20.0VInternal fuse protectionDimensions (L x W x H): 17.5" x 8" x 6"Weight: 17 lbs (unit), 19 lbs (boxed)UL maximum recommended per outlet: 1500WFree 1-year tech support1-year warranty on parts and laborInstruction manual includedPre-wired for remote on/off switch and pre-slotted mounting plate
