American Forge & Foundry 30-Ton Super Duty Bottle Jack (3630)

The American Forge & Foundry 30-Ton Super Duty Bottle Jack (3630) is a robust and reliable hydraulic lifting solution engineered for the most demanding heavy-duty applications. Designed to provide dependable power for heavy trucks, large equipment, and challenging oil field jobs, this jack combines substantial lifting capacity with a construction built for continuous, rigorous use. Its high-grade steel construction, fully welded cylinder, and precision-manufactured internals ensure stability and consistent performance when lifting loads up to 60,000 pounds. Each unit is built to exacting standards, featuring critical stress areas that are heat-treated for extended service life and sustained performance under pressure. With a low height of 10.8 inches and a maximum high height of 17.32 inches, it offers a versatile lifting range for a variety of tasks. The integrated oil bypass valve provides essential overload protection, safeguarding the jack and promoting safe operation. Compliant with ASME PASE 2019 Safety Standards, the AFF 30-Ton Super Duty Bottle Jack is a secure and effective tool for professionals in the agriculture, mining, heavy hauling, and industrial sectors.

KEY FEATURES AND BENEFITS:Exceptional Lifting Capacity: Provides a substantial 30-ton (60,000 lb) lifting capacity, making it suitable for a wide range of heavy trucks, agricultural machinery, and industrial equipment.Robust Construction: Made from high-grade steel with a fully welded cylinder and a forged base, ensuring maximum strength, stability, and leak-free operation in demanding environments.Enhanced Service Life: Precision-manufactured internals and heat-treated critical stress areas contribute to prolonged operational life and consistent performance under heavy loads.Integrated Overload Protection: Features an oil bypass system that prevents hydraulic damage from exceeding the rated capacity, enhancing safety and the jack’s longevity.Versatile Lift Range: Offers a low height of 10.8 inches and an extendable high height of 17.32 inches, accommodating various lifting requirements.Safety Standard Compliance: Meets ASME PASE 2019 Safety Standards, providing assurance of its design and operational safety for professional applications.SPECIFICATIONS:Base Length: 7.95 inchesBase Width: 5.91 inchesCapacity: 30 Tons (60000 lb)Standards: ASME PASE 2019 Safety StandardDuty Level: Super Heavy DutyHandle Length: 16.5 inchesNumber of Handle Pieces: 2Operation: HydraulicType: Bottle JackHigh Height: 17.32 inchesLow Height: 10.8 inchesRam Lift – Stage 1: 6.5 inchesWeight: 24.9 lbHOW TO USE:Preparation: Ensure the jack is on a solid, level surface. Position the jack directly under the vehicle’s or equipment’s designated lifting point. Ensure the load is stable and chocked if necessary to prevent movement.Lowering the Saddle: Turn the release valve counter-clockwise slowly to lower the saddle completely. Once lowered, close the valve by turning it clockwise firmly.Positioning: Adjust the extension screw (if present and needed) by turning it clockwise until it makes contact with the lifting point.Lifting the Load: Insert the handle into the handle socket. Pump the handle steadily up and down. This will raise the ram and lift the load. Continue pumping until the desired height is reached.Securing the Load: Once the load is lifted, immediately place appropriately rated jack stands under the vehicle or equipment for support. Never work under a load supported only by a hydraulic jack.Lowering the Load: With the load supported by jack stands, slowly turn the release valve counter-clockwise to lower the jack’s ram. Once the ram is fully retracted, remove the jack.Storage: Clean the jack and store it in a dry, safe place.BENEFITS OF USING AMERICAN FORGE & FOUNDRY 30-TON SUPER DUTY BOTTLE JACK (3630):Provides significant lifting power for the heaviest vehicles and machinery, streamlining maintenance and repair tasks.Offers a dependable and stable lift, reducing the risk of accidents during operations.Designed for a long service life, reducing the need for frequent replacements and offering a good return on investment.Its safety features, such as overload protection, contribute to a safer working environment.The versatile lifting range makes it adaptable to various heavy-duty applications across multiple industries.Built to professional standards, ensuring that it can withstand the rigors of commercial and industrial use.FEATURES:Precision-engineered internal components for smooth operation.Solid, forged base provides an extra layer of stability.Heavy-duty cylinder designed to prevent hydraulic fluid leaks.Safety mechanism to prevent lifting beyond the rated weight.Constructed from high-strength steel for overall integrity.Critical stress points are specially heat-treated for enhanced strength.Features an extension screw for fine-tuning lift height.Manual hydraulic operation for controlled lifting.Two-piece handle for convenient assembly and storage.
