Baileigh 220V 1Phase Variable Speed Vertical Milling Machine 9 x49 Table (1008232)

Baileigh 220V 1Phase Variable Speed Vertical Milling Machine 9″x49″ Table (1008232) is designed to meet the needs of small to medium-sized machine shops and fabrication shops. This fully variable speed milling machine allows infinite adjustment from 60 to 4200 rpm, ensuring optimal performance and prolonged tooling life.

The VM-949, powered by a 3 hp motor, runs on 220-volt single-phase power, making it suitable for a wide range of shop environments. The variable speed milling machine offers adjustable spindle speeds for various applications, including thermal friction drilling.

Specifications and Dimensions Length: 72 in. Width: 72 in. Height: 72 in. Net Weight: 2400 lbs Table Size: 9″ x 49″ Spindle Speeds: 60 to 4200 RPM Spindle Center To Column Min Max: 8.38″ Spindle Diameter: 3.37″ Spindle Feed Per Rev: .0015″/.003″/.005″ Spindle Head Swivel: 45 Motor Spindle: 3 hp Spindle Nose To Table Min Max: 2.24″ Table Load Capacity: 440 lbs. T Slots: .625″ Cross Travel Of Ram: 12.59″ Power: 220V / 1-phase

Key Features and Benefits Fully variable speed control for precise machining Yaskawa® inverter drives for adjustable spindle speeds NST 40 spindle taper for better performance Large, durable table for versatile operations Powered X, Y, and Z axes for easy operation Mitutoyo® digital readout for accurate measurements Integrated coolant system with catch tray Air draw bar for quick tool changes Robust castings for enhanced rigidity and stability Covered by a 1-year parts warranty Lifetime technical support by phone from Baileigh experts
