PCE Instruments Process Clamp Meter (PCE-MCM 10)

PCE Instruments Clamp Meter (PCE-MCM 10) is a highly precise process clamp meter designed for measuring DC current up to ±99.9 mA. It features a detachable sensor connected via a 1-meter cable, allowing hands-free operation while monitoring readings with an accuracy of ±0.3%.

For added convenience, the clamp meter is equipped with an LED light to illuminate the measuring area, making it easy to use in low-light environments. The device includes an automatic power-off function to extend battery life, with an estimated runtime of 40 hours.

Specifications and DimensionsMeasuring Range: ±20.99 mA DCResolution: 0.01 mAAccuracy: ±(0.3% of rdg. + 8 Digits)Extended Measuring Range: ±21.0 … ±99.9 mA DCResolution: 0.1 mA DCAccuracy: ±(1% of rdg. + 8 Digits)Clamp Opening Diameter: Ø5 mmSwitch-Off Function: Automatic after 10 minutesOperating Voltage: 3V (2 x AA batteries)Battery Life: Approx. 40 hours of continuous useProtection Class: IP40Overvoltage Category: CAT II 300VOperating Conditions: -10 … 50°C / 14 … 122°FStorage Conditions: -15 … 60°C / 5 … 140°FEnvironmental Humidity: <90% RH at < 30°CWorking Altitude: 0 … 2000 m (6,561 ft) above sea levelHandheld Device Dimensions: 180 x 55 x 39 mm / 7.1 x 2.2 x 1.5 inClamp Dimensions: 90 x 40 x 1.5 mm / 3.5 x 1.6 x 0.06 inCable Length: Approx. 1 m / 3.3 ftWeight: 268 g / 0.6 lbs with batteries inserted

Key Features and BenefitsHigh-precision DC current measurement with ±0.3% accuracyDetachable clamp with a 1-meter cable for hands-free operationBacklit display ensures clear readings in various lighting conditionsLED light for improved visibility in dark work areasCompact and lightweight design for easy portabilityAutomatic power-off function extends battery lifeIdeal for process control, calibration, and maintenance applications

Includes1 x Clamp Meter PCE-MCM 102 x AA Batteries (3V)1 x Instruction Manual
