Shop Fox 1/2 HP 34 Bench-Top Radial Drill Press with Sliding Headstock (W1669)

Shop Fox 1/2 HP 34″ Bench-Top Radial Drill Press with Horizontal Sliding Headstock (W1669) offers versatility and precision in one compact machine. Ideal for both small hobby shops and professional machine shops, this drill press provides unmatched flexibility with its radial arm and oscillating features.

Equipped with a powerful 1/2 HP motor, this Shop Fox drill press W1669 features a 17″ swing and a 1/16″ to 5/8″ drill chuck capacity. With five-speed settings ranging from 550 to 3470 RPM, it provides the flexibility needed for various drilling tasks.

Specifications and Dimensions Motor: 1/2 HP, 110V Swing: 17″ Drill chuck: 1/16″ – 5/8″ Arbor: JT-33 Spindle travel: 3-1/4″ Number of speeds: 5 Range of speeds: 550-3470 RPM Table size: 9-3/4″ dia. Table tilt: 90° left & right Head tilts: 45° left & 90° right Horizontal sliding headstock Overall height: 31-1/2″ Approximate shipping weight: 100 lbs. CSA Certified

Key Features and Benefits Compact design with radial arm for increased versatility Powerful 1/2 HP motor for heavy-duty tasks Five-speed settings for various drilling applications Large 9-3/4″ diameter table with 90° tilt for precise drilling Horizontal sliding headstock for enhanced flexibility
