Victron SCC020030200 BlueSolar MPPT 100/30 Victron Energy

Victron SCC020030200 BlueSolar MPPT 100/30 Victron Energy

TheVictron BlueSolar charge controllergets connectedbetween the photovoltaic modules and the batteriesallowing the product toincrease energy harvestout of the modules as efficiently as possible.

Key Features

Ultra-fast Maximum Power Point Tracking (MPPT)Advanced Maximum Power Point Detection in case of partial shading conditionsOutstanding conversion efficiency with no fan cooling exceeding %98Fully programmable charge algorithm with eight pre-programmed algorithms, selectable with a rotary switchExtensive electronic protectionInternal temperature sensorReal-time data display using VictronConnect application.3 Charging stages: Bulk – Absorption – Float

The Victron BlueSolar Charge Controller has anultra-fast Maximum power point tracking (MPPT) controllerthatimprovesthe energy harvest by30% compared to PWM controllersand by up to10% compared to the slower MPPT controllers. Especiallyin the clouded skywhen the light intensity is changing continuously.

The Victron BlueSolar Charge Controller uses theadvanced Maximum Power Point Detectionin cases ofpartial shadingconditions. at times of partial shading happenstwo or more maximum power points can be presented on the power-voltage curve. Conventional MPPTs tend to lock to a local Maximum Power Point (MPP), which may not be optimum; however, the innovative BlueSolar algorithm willalways maximize the energy harvest by locking to the optimum MPP.

This Victron BlueSolar charge controller comes with theremote management possibilityusing yoursmartphoneor otherBluetooth-enabled devices. This feature can be used tocontrol,monitor, andupdatethe system wirelesslyin the comfort of your homeusing the VictronConnect application (you will need a Bluetooth dongle). You also be connected directly to a Color Control GX, computer, or other devices.

The BlueSolar charger is equipped with aninternal temperature sensorto compensate for the charging voltageaccording to its temperature. If the system temperature rises, the controller’sExtensive electronic protectionwill automatically reduce its output current (temperature >40°C). In addition to the mentioned protection systems, also this system is equipped with safety devices against overheating,short circuits,polarity reversal, andmodule current reversal.

Additional information:

brand: Victron Energycharge-current-a: 30dc-system-voltage: 12 Vheight-1: 13length-1: 9lithium-compatible: Nomaximum-input-voltage: 100 Vwidth-1: 20.5
