Jet JMD-45GHPF Sq. Col. Mill/Drill DP700 2-Axis DRO & X Pwrfd (351153)

The Jet JMD-45GHPF Sq. Col. Mill/Drill DP700 2-Axis DRO & X Pwrfd (351153) is a heavy-duty machine designed for tackling a variety of drilling and milling tasks in workshops and professional environments. It combines the functionality of a drill press with the precision of a milling machine, making it a versatile tool for metalworking applications.

KEY FEATURES AND BENEFITS:Powerful Performance: The 1.5 HP motor provides ample power for drilling and milling through various materials. The 6-speed geared head allows for variable spindle speeds to match the specific needs of the project.Enhanced Precision: The square column with dovetail ways minimizes deflection for increased drilling and milling accuracy. The 2-axis DRO system (Digital ReadOut) provides real-time digital readouts of the quill and table positions for precise movement control.Automated Functionality: The power downfeed feature automates quill movement, reducing operator fatigue and ensuring consistent drilling depths. The X-axis powerfeed allows for automated table movement, streamlining repetitive milling operations.Wide Range of Capabilities: The R8 spindle accepts a variety of drill bits and milling tools, enabling the machine to handle diverse drilling and milling applications. The large table with T-slots provides a secure platform for workpieces of various sizes.Durable Construction: The heavy-duty design ensures long-lasting performance and stability even in demanding environments.SPECIFICATIONS:Drilling Capacity: 1-1/2 in.Face Mill Capacity: 4 in.End Mill Capacity: 3/4 in.Swing: 19-11/16 in.Spindle Travel: 5 in.Quill Diameter: 3 in.Number of Spindle Speeds: 6Spindle Speed Range: 65-1550 RPMTable Size: 9-1/2 x 32-1/4 in.Table Longitudinal Travel: 20-1/2 in.Motor: 1-1/2 HP, 115/230V, single-phaseOverall Dimensions: 29 x 36 x 50 in.Weight: 820 lbs.HOW TO USE:Setup: Secure the workpiece onto the mill/drill table using clamps or a vise. Ensure the chosen drill bit or milling tool is properly installed in the R8 spindle.Adjustments: Select the appropriate spindle speed based on the material and drill bit/milling tool size. Use the quill feed handle or power downfeed function for precise depth control during drilling. For milling, set the desired table feed rate using the X-axis powerfeed or manual controls.Operation: For drilling, engage the quill feed or power downfeed and lower the drill bit into the workpiece to create the desired hole. For milling, start the spindle and use the table feed controls (manual or X-axis powerfeed) to move the workpiece against the rotating milling tool to achieve the intended shape.Safety: Always wear safety glasses and appropriate gloves when operating the mill/drill. Ensure the machine is turned off and unplugged before making any adjustments or changing tooling.BENEFITS OF USING Jet JMD-45GHPF Sq. Col. Mill/Drill DP700 2-Axis DRO & X Pwrfd (351153):Increased Efficiency: The combination of drilling and milling functionalities in a single machine streamlines workflows and reduces setup times.Enhanced Accuracy: Power downfeed, 2-axis DRO, and a rigid square column design contribute to precise drilling and milling results.Versatility: The machine’s capabilities handle various drilling and milling tasks, making it a valuable asset for diverse metalworking projects.Durability: The heavy-duty construction ensures long-lasting performance and reliable operation in demanding environments.FEATURES:Heavy-duty design for stability and durability.6-speed geared head for variable spindle speeds.Square column with dovetail ways for rigidity.Power downfeed for automated quill movement.2-axis DRO for precise positioning.X-axis powerfeed for automated table movement.R8 spindle compatible with various tooling (optional mill drill stand).Easy-to-read internal depth gauge.Head tilts left & right 90°.Forward/reverse switch.
