Jet JVM-836-1 Milling Machine with ACU-RITE 203 DRO (690177)

The Jet JVM-836-1 Milling Machine with ACU-RITE 203 DRO (690177) is a versatile and precise machine tool designed for various metalworking applications. It boasts a precision-bored head for accurate cuts and reduced chatter, along with a spacious 8×36 inch table to accommodate larger workpieces. Double locks on moving surfaces ensure stability and operator safety during operation.

KEY FEATURES AND BENEFITS:Precision Machining: Delivers accurate cuts with a precision-bored and honed milling head.Versatility for Various Projects: Handles a wide range of metalworking tasks with its large table size and multiple speed options.Easy Control and Measurement: Simplifies positioning and measurement through the ACU-RITE 203 DRO system.Enhanced Stability and Safety: Features double locks on all moving surfaces for secure operation.Durable Construction: Built with a hardened and ground table for lasting wear resistance.User-Friendly Maintenance: Equipped with a one-shot lubrication system for easy upkeep.SPECIFICATIONS:Spindle Taper: R-8Table Size (L x W): 7-7/8 x 35-3/4 in.Number of Spindle Speeds: 5 (240 – 1,550 RPM)Quill Feed Rates: .0015, .003, .006 in/revSpindle Travel: 5 in.Table Longitudinal Travel: 22-1/4 in. (18 in. with power feed)Table Cross Travel: 9-1/2 in.Motor: 1-1/2 HP, 115/230V, 1PhOverall Dimensions (L x W x H): 55 x 52 x 78 in.Weight: 1,617 lbs.HOW TO USE:Assembly and Setup: Follow the manufacturer’s instructions for proper assembly and installation of the milling machine. Ensure the machine is level and securely fastened to a stable workbench.Workpiece Preparation: Secure your workpiece firmly to the table using clamps or a vise, ensuring proper clearance between the tool and the workpiece.Selecting Speed and Feed: Choose the appropriate spindle speed and quill feed rate based on the material being machined and the desired cut depth. Refer to a machining chart for recommended settings.Positioning and Machining: Utilize the handwheels and DRO system to precisely position the cutting tool and workpiece. Engage the spindle motor and gradually lower the quill to initiate machining.Machine Maintenance: Regularly clean and lubricate the machine as per the manufacturer’s guidelines. Maintain sharp cutting tools for optimal performance.BENEFITS OF USING Jet JVM-836-1 Milling Machine with ACU-RITE 203 DRO (690177):Achieves Precise Results: Delivers clean and accurate cuts with its rigid construction and high-quality components.Increases Efficiency: Streamlines metalworking projects with its spacious worktable, multiple speed options, and easy-to-use DRO system.Enhances Safety: Ensures operator safety with its double lock mechanisms and robust design.Durable Performance: Built to last with a hardened table and user-friendly lubrication system.FEATURES:Precision-bored and honed milling headLarge 8×36 inch tableDouble locks on moving surfacesFive-speed spindle (240-1,550 RPM)Three quill feed rates (.0015, .003, .006 in/rev)ACU-RITE 203 DRO for digital readoutHardened and ground tableOver 10 inches of ram travelHead tilts for angle millingOne-shot lubrication system
